If at first you don't succeed

Started out with the vague notion to make a phone holder.  I already have a design for a clip to hook on to the lip of the dash from another project.  So, how hard can it be?     Modeling this guy was straight forward. The piece tilts up and in toward the driver.   After 14 hrs of printing, I was rewarded with this mess.  It turned out that the part printed as one piece was not did not have all the printed layers in the ideal alignment to take any amount of mechanical stress due to the shape of the part.   Plan B.   Broke the design up into pieces.  Many many hours later since I still am horrible at 3D modeling.  Each piece can be printed individually.  Total printing time should be about 4 hrs.    Many many prints later for fit check since material shrinkage was next to impossible to predict.   Voila, the clip worked perfectly.  The holder held.  Life is good.

Tsingtao_1903

Tsingtao_1903

Introduction

Noticed my Blog wasn't showing up until I added an entry, so I copied the description to here.    After sitting for most of its life its time to give this gorgeous low mileage example a restoration worthy of the record books. I purchased this car from the second owner. He bought it back in the early 80s while living in Germany before driving it to Italy where he lived. When it came time for him to move to the US he had trouble selling the car and decided to bring it to New York with him where the car ultimately sat until it could be legally titled once it was 25 years old. By then the owner had swapped in us market side markers and an American speedometer as requested by the DMV at the time. The odomoter reads just over 30,000 miles and from my overall inspection of the vehicle I believe it to be accurate. Being a North East car that sat in a mechanics backyard for a number of years a full restoration is in order and will be completed using many connections I've formed with some of the best automotive talent in the USA. Today marks the official project start date, and the car is headed to my good friend Matt's shop, Beaver Built. The project begins with major surgery- rust repair. At least one subframe mount will need to be cut out, and many more spots including the usual suspects will be discovered and fixed as the project progresses. Following rust repair the car will be shipped to me in California where I now reside and be stripped to a bare shell for a clean start to a very lengthy project. I have some very wild engine plans but the car will retain a very mild appearance with practicality improvements integrated as cleanly as possible.    Be sure to follow my Instagram for more up to date updates @rocanmotor as well as my friend Matt's shop @beaverbuilt for all the nitty gritty. I'll keep this post updated as much as possible.   I apologize to all my 02 friends here for my long hiatus... Between starting my career and making a few big moves in the past three years I've had to put the 02 projects aside for a bit. I've worked on some stuff in the meantime but I've never really been happy not having an 02 in my life.   Let the fun begin.

Rocan

Rocan

Jumping the Shark

So in trying to remove the diff from the drive shaft, I was poking around the underside of the car and discovered something fairly alarming. At some point, the nuts holding the transmission brace had rattled off, and the whole brace had fallen onto the exhaust. It wasn't that far off, not even the length of the studs extending under the car. Maybe half an inch total lower then it should be. However, I think we all know that an exhaust should not be holding your transmission in the car. Discovering this, I made a snap decision to just pull the engine.
    Here's my logic... Since I purchased this car, I've been less than impressed with the plumbing and wiring. It always felt like a rush job. The previous owner told me that he brought it to a shop in his area to have them complete those two areas, and they clearly just phoned it in. While it is functional, the car did run after all, it is ugly and completely unservicable. For example, if the shift linkage failed, the exhaust would have to come out completely to reach it. In order to remove the exhaust, the subframe has to come out. This is because the exhaust is one piece front to back, a removable mid section would prevent this. Same with the wiring, the radiator fan wiring ran a full loop of the engine bay for no apparent reason, and every single wire coming off the relay was the same color. These are details that make working on the car a nightmare.

So time to redo everything.

First the hood came off. Side note, Jesus Christ the 2002 has a heavy hood. Like surprisingly so. You can see I started moving things around in the engine bay. I cut the exhaust off the car underneath, but the bolts from the header to the midsection were seized, so it's stuck together. I can't drop the exhaust out the gap, so it'll have to come out after the engine. It is free from the car entirely though.        Below are some examples of the things that drive me nuts about this swap. The wiring is zip tied to coolant hoses, relay blocks are shoved where ever they'll sit, dead systems just remain in the car for no real reason. I found quite a few wires sitting in the engine bay that just generally lead no where on either end.          These zip ties were all removed from coolant hoses. Almost all of them were tightened to the point where they were digging into the hose. In many cases wiring harness portions were also ziptied to the hose, and then the whole lot was zip tied to the chassis. Look, zip ties are useful in moderation. But this engine bay basically fell apart when I started removing zip ties.      I finished the weekend removing the intake manifold. A hateful job that was 100% designed by someone who had a grudge against people with big hands. I spent far too much time removing that manifold from the engine. I wanted to do it in the bay to give myself more room to extract the engine, but I borderline regret doing that now. It ate up hours. The cooling system was removed as well, and the wiring harness was labeled and separated from the engine as best as I could. I'm sure we'll discover how good a job I did when the engine comes out.      Once the engine is out, it's time for some clean up. I'll be cutting off any brackets that are not needed, plugging any holes that serve no purpose, and sending the car off again for some fresh engine bay paint. I won't call it a shaved bay, but... trimmed? Yeah, sure trimmed bay. I also ordered something I'm extremely excited about, this part is the crowning jewel to this car. It'll realize the dream 2002 for me. I'm being intentionally vague until they get in, so in the mean time, here's a picture of my dog.
